Technical Data Sheet : DC COMPRESSOR R134a Series
  Model Power supply (V/rpm) Displacement (cm3) Cooling Capacity(W)   COP (W/W)   Motor Type
DL19H  12~24/2000 1.9 32 1.00 BLDC
12~24/3500 60 1.15
DL22H  12~24/2000 2.2 39 1.20 BLDC
12~24/3500 70 1.25
DL30H  12~24/2000 3.1 57 1.20 BLDC
12~24/3500 100 1.25
DL35H  12~24/2000 3.5 64 1.20 BLDC
12~24/3500 110 1.25
VDL19H  12~24/2000 1.9 32 1.00 BLDC
12~24/3500 60 1.15
100-240/2000 32 0.85
100-240/3500 60 1.00
VDL22H  12~24/2000 2.2 39 1.20 BLDC
12~24/3500 70 1.25
100-240/2000 39 1.00
100-240/3500 70 1.05
DM14H  12~24/2000 1.4 14 0.85 BLDC
12~24/4000 38 0.95
DM16H  12~24/2000 1.6 16 0.85 BLDC
12~24/4000 44 1.10
DM19H 12~24/2000 1.9 32 1.15 BLDC
12~24/4000 60 1.20
DW16H  12~24/2400 1.6 20 0.90 BLDC
12~24/4200 46 1.10

Test conditions  ASHRAE                 According to
Evaporating temperature -23.3℃℃
Condensing temperature 54.4℃
Subcooling temperature 32.2℃
Suction temperature 32.2℃
Ambient temperature 32.2℃
        (R134a L/M/HBP)
  Model   Power supply (V/rpm)     频率 Frequency (Hz) Displacement (cm3 Cooling Capacity(W)   COP (W/W) Motor Type
DK52G  12~24/2500 5.2 450 2.80 BLDC
12~24/4000 700 2.60

Test conditions  ASHRAE                 According to ASHRAE
Evaporating temperature 7.2℃
Condensing temperature 54.4℃
Subcooling temperature 46.1℃
Suction temperature 35℃
Ambient temperature 35℃
Working condition limit:R134a
Max ambient temperature 55[℃]
Evaporation temperature range -35~15[℃]
Working voltage range 12/24V [DC],100-240V [AC]
Max discharge pressure 1.79[Mpa]   gauge pressure
Max allowable housing temperature 85[℃]
 max pressure housing endured 3.5 [Mpa]   gauge pressure
Low voltage start 0.7/0.7Mpa( gauge pressure) 10.8V/22.7V[DC];100V[AC]
